STEL X580 Fully-Automatic AC Service Unit

X580

Automatic A/C service station for 1234yf

Premium equipment for A/C service

The fully automatic X580 1234yf A/C service unit combines all maintenance functions — recovery, vacuum, and charging — in one device. Featuring a 10-inch touchscreen, five digital scales, and four sealed oil bottles, it ensures precision and prevents contamination. With a leak test function, dual ventilation system, and over 95% recovery efficiency, it safely handles the highly flammable 1234yf refrigerant. The built-in database and printer allow easy updates via SD card and can print detailed service reports. Its self-protection system halts operation if the fan stops, while the user-friendly interface and intuitive menu make operation simple and reliable.



Item	Specification / Description
Refrigerant	R1234yf
Vehicle type	Gasoline / Diesel / Hybrid / Electric
Voltage	AC 220V
Power	1200W
Working Temperature	-20°C ~ +60°C
Display	10-inch touch
Oil Bottle	4 × 350ML (PAG / POE / Used oil / UV)
Scale	PAG / POE / Used oil / UV / internal storage vessel
Scale Accuracy	10g
Recovery Efficiency	95%
Recovery Ability	3/8 HP
Vacuum Pump	170L / min
Tank Capacity	18kg
Dry Filter Ability	100kg
Dimension	1344mm (H) × 644mm (D) × 784mm (W)
Weight	109kg



Feature	Description
10-inch touch screen	Fully digital display and control, with service prompts step by step.
Flushing Hoses	Automatic internal system cleaning to avoid mixing of different compressor oils.
5" High-precise Electronic Scales	Enables accurate measurement and charging of internal storage vessel, PAG oil, POE oil, UV, and drained oil bottles.
Deep Recovery Mode	Improves recovery efficiency up to 95%.
Patent Design Oil Bottle	Prevents contamination of new oil from air contact.
High-sensitivity Sensor	Accurately detects A/C system and equipment leaks.
Configure the Printer	Prints maintenance data and workshop information as required.
Built-in Refrigerant Database	Includes 20,000+ vehicle models; database can be updated as required.
